What polarity do you use for 6011?

6011 runs on AC and direct current electrode positive (DCEP), while 6010 runs only on DCEP.

Is 6011 DCEP or DCEN?

E6011 is a multi-purpose electrode for stick welding that can be welded with DCEP, DCEN, and even AC. It is not common to stick weld in DCEN, but it can be done with the aggressive E6011 to prevent over penetration in the base metals.

Which rod or electrode polarity is best for welding sheet metal E6011 or e6013?

The 6013 electrode is best used for light to medium penetration on a thin metal, or sheet metal. The 6011 electrode offers more penetration than the 6013 so you can weld a slightly thicker material.

about 85 amps is a good place to start. Much colder and your puddle will not flatten out. Much hotter and you might struggle with arc blow toward the end of each rod. machines differ and some folks like to weld hotter, but 85 amps will get you in the ball park.

Can you reverse polarity on an inverter welder?

Welders that output AC current have no need to refer to polarity. So if you are welding with an old AC buzz box welder, polarity is of no consequence to you. But if you are welding with new inverter welder, or even an old DC transformer welder, it is. Reverse polarity refers to positive polarity.

DCEP provides a more stable arc in general in stick welding, but for welds requiring light penetration, use DCEN if the electrode is designated to run either polarity.

Can you weld 6011 on DC?

While the 6011 was specifically designed for AC machines, it can also run on DC giving it an advantage over the 6010 electrodes (which can only do Direct Current Electrode Positive). A common mistake for Stick welders is to treat their 6013 electrodes like 6011 or 6010 rods.

What are 6011 rods good for?

The 6011 welding rod is useful for jobs that require deep penetration, no matter the position or welder setup. It is a solid all-around welding rod. Because it is an iron rod, it is useful for most kinds of iron and mild steel. You can handle just about anything with 6011 rods.

I’ve used 6011/6013 rods in a few instances that the weld didn’t need to be stainless or pretty. Had a guy I worked with used to surface ripper points with 6011, but it’s not ideal. You can weld most stainless with mild steel wire or rod, the welds will be softer than the steel and will rust.

How strong is a 6011 Weld?

Metal Web News claims that 6011 welding rods are capable of producing welds that feature a 60,000 psi minimal tensile strength. The 7018 welding rods produce stronger welds that feature minimal tensile strengths of 70,000 psi.

What’s the difference between E6011 and E6013?

Like E6010 electrodes, E6011 electrodes produce a deep, penetrating arc that cuts through corroded or unclean metals. E6013 electrodes produce a soft arc with minimal spatter, offer moderate penetration and have an easily-removable slag. These electrodes should only be used to weld clean, new sheet metal.

What’s the difference between 6011 and 6013 Rod?

The 6013 welding rod offers light to medium penetration which can be used to weld thinner materials while the 6011 electrode offers a deeper penetration which will allow you to weld slightly thicker metals.

6011 high cellulose coated electrodes provide excellent arc stability, increased ductility, high deposition efficiency and low spatter. This electrode combines a strong arc force with fast solidification of weld metal, thereby permitting vertical or overhead as well as flat and horizontal welding positions.

What does the E stand for in E6011?

SMAW Electrodes

Let’s take the electrode E7018 as our point of departure in order to explain the numbering system. E – This signifies that the rod is a current-carrying electrode. 70 – These two digits indicate that there 70,000 psi (pounds per square inch) of tensile strength in the weld.

Can you weld downhill with 6011?

6011 rods weld all positions and all directions uphill and downhill both can be donedownhill welding is no problem. 6011 stick rods work on all polarities and being able to weld with AC eliminates arc blow (arc blow is what happens when magnetic forces build up and cause the electrode to burn unevenly)
