Do you have to thin paint for Graco sprayer?

Is it necessary to Thin Latex Paint for Spraying? Yes, the latex paint does need to be thinned. Even though latex paint is water-based, it is thicker than the oil-based paint varieties. The thick latex paint needs to be thinned to be able to spray a fine mist of paint.

What size tip comes with Graco Project Painter Plus?

The Project Painter Plus includes a “515” spray tip, which is great for painting large surfaces with thicker paints, but you’ll want to check the matrix (or the back of your paint can) to determine the proper tip for your job.

Why will my Graco paint sprayer spray water but not paint?

My sprayer sprays water but not paint? Debris is caught in the sprayer. Try reversing the spray tip 180 degrees to see is paint can be sprayed. If it can, turn the spray tip back to the spray position to spray.

How do you get air out of a paint sprayer?

Air in pump or hose. Hold spray gun trigger in open position and run about 10 seconds until air is purged. Check for siphon tube leak.

Why is my sprayer losing pressure?

If you are experiencing low pressure output from your sprayer and have ruled out any other parts as the cause, the impeller coupling may have lost its seal, or the impeller itself may be damaged, clogged or broken. In some cases, the pump may be disassembled and cleaned to fix the problem.

What is the ratio of paint to thinner for spray gun?

Use small amounts of thinner at a time. Check paint container labels for the manufacturer’s recommended paint to paint thinner ratio. For general purpose thinning, a 3:1 or 4:1 ratio of paint to thinner or similar ratio is appropriate. It is important to keep the amount of paint higher than the amount of paint thinner.

How do you know what size spray tip to use?

Choose a tip with an orifice size rated for the paint or coating you’ll be spraying. Light coatings such as lacquers, stains, and enamels require a small tip, while heavier coatings such as texture require larger spray tips.

What is a 311 spray tip used for?

The reversible RAC IV SwitchTips are the most widely used tip for spraying a variety of coatings from lacquers to exterior paints. Use the Reverse-A-Clean (RAC®) feature to quickly clear tip clogs by simply twisting the tip and spraying in the reverse position.

What is a 619 spray tip used for?

The TrueAirless Spray Tip with SoftSpray Technology delivers a softer spray pattern to make it easier to deliver a professional quality finish. Achieve greater control and less overspray on different surfaces with a wide range of coatings, from stains to exterior paints.
