What is combustion air for a water heater?

What is combustion air? It is the air necessary for a gas appliance such as a water heater to function properly. Not to get too basic here, but gas appliances require a certain amount of air to be used for combustion, much the same way that the fire in your fireplace needs air to get started and to keep burning.

Does water heater need combustion air?

In addition to venting, gas and propane water heaters need an air supply for combustion. This may come from the atmospheric air in the house, or it can come through a vent pipe that pulls air from the outdoors.

What happens if there is not enough combustion air?

Lack of adequate combustion air causes improper heater operation, increased maintenance cost, and risks dangerous production of carbon monoxide gas.

Do hot water heaters need fresh air?

As a general rule, water heaters need 50 cubic feet of air per 1,000 BTUs/hr. For example, a water heater with an input of 40,000 BTUs/hr should be in a room (often the garage) with at least 2,000 cubic feet of air.

How much combustion air is needed?

A furnace must be supplied a specific amount of fresh air per cubic foot of gas burned. To burn 1 cubic foot of gas, approximately 1,000 Btu for natural gas, requires 10 cubic feet of air for perfect combustion (Figure 2).

Can you pull combustion air from a bedroom?

The most common solution is to get combustion air from the rest of the house. This is done simply by putting vent openings in the furnace room to connect it to other rooms in the rest of the house and allow air to get in. This will work as long as the rooms combine to meet the 50 ft3 per 1,000 BTU/hr input requirement.

How do you calculate the size of a louver combustion air?

Step 6–To find the required grille/louvers size, you will need the Total BTUs of the appliances(from Line 1). The total BTUs should be divided by 1000. This will give you the SQUARE INCHES required to connect the spaces. Each room that is required for combustion air will need these grilles/louvers installed.

Is a power vent water heater worth it?

Power vent water heaters are more energy efficient, so they require less gas to operate. The lower energy consumption will save you some money, but probably not more than $20 a year, making this an added benefit, but not a deciding factor.

What causes a water heater to backdraft?

The main reasons for backdrafting at the water heater are the poor vent installation and obstructions found in the vent pipe. This problem affects mainly the atmospheric gas type water heaters that use natural convection to remove the combustion products, known as exhaust gases.

Why is combustion air important?

Combustion air is a source of oxygen needed to burn fuel such as natural gas or liquid propane (LP). You can’t produce a flame in a furnace without proper combustion air.

Is it OK to enclose a water heater?

In most instances, a home’s water heater is placed in the basement. When the basement is finished so it can be used for another purpose, leaving the water heater in plain view can detract from the appearance of the room. You can enclose the water heater by building a wall around it and constructing a utility closet.

Can I use PVC to vent gas water heater?

A standard will be needed for plastic flue pipes that should include a temperature gauge and a high limit probe. Then PVC, CPVC and polypropylene flue gas piping can be safely used on high efficiency boilers and water heaters.

Can you put a hot water heater in a closet?

Water heaters can be installed in bedroom or bathroom closets, if necessary or preferred, but only if they’re an electric, direct vent or sealed combustion chamber unit. Other water heaters that use fuel combustion are not permitted to be installed in bedrooms, bathrooms or closets that open into these rooms.

How do you test for combustion of air?

Combustion Testing Procedures. The measurement for gases and temperature should be taken at the same point. Typically, this is done by selecting a sample location ‘upstream’ from the draft diverter/hood, barometric control or any other opening, which allows room air to enter and dilute flue gases in the stack.

How do you size a fresh air intake?

In order to size fresh air intake into attic spaces from the eaves to feed interior ceiling air inlets, take the total ventilation (in cfm) that will be provided by the fans and divide that number by 400 feet per minute.
