How do you activate an ARB Air Locker?

General ARB Air Locker Use

ARB Air Locker differentials can be engaged and disengaged at the flip of a switch. When you need the extra traction, simply turn on your compressor, approach the difficult terrain, take your foot off of the accelerator and press the Air Locker switch – even if you are still moving.

How do ARB air lockers work?

When the switch is pushed, a solenoid on the remote-mounted ARB air compressor opens up a port sending a high-pressure stream of air to the Air Locker, causing the clutch gear to engage the side gear. The air compressor will then run for a short amount of time to replenish the small tank of compressed air.

How much air does an ARB locker need?

What is the minimum and maximum air pressure required to operated an ARB Air Locker. The ARB Air Locker will engage at around 70 PSI. However, for faster engagement and disengagement, we recommend an air pressure supply between 100 and 150 PSI.

Are ARB air Lockers good?

After years of testing, we have found that ARB Air Lockers are strong and can take a beating. Yes, ARBs are more complicated in design than other lockers, which has lead to some people fearing the Air Locker.

Where are ARB air Lockers made?

ARB Air Lockers®

Designed and manufactured in Australia, ARB Air Lockers locking differentials will enhance the traction of your 4×4 in just about any terrain, whether it’s rock, clay, gravel, sand, snow or mud.

How do I know if my differential is locked?

Hand turn the wheel on one side. If you have a locking differential the opposite wheel will turn the same direction. If it is not a locking differential the opposite wheel will rotate in the opposite direction. Be very careful and do not get any part of your body under any part of the car while it is jacked up.

Are Detroit Lockers noisy?

Detroit lockers make a lot of noise when you go around corners. The best I remember they are like a ratchet and click on corners. They also put the power to the inside wheel on a turn. That causes the outer wheel to go faster and that in turn causes the outer wheel going faster to cause the clicking noise.

How do automatic lockers work?

An auto locker replaces the standard gears in a vehicle’s differential housing, allowing the diff to be locked automatically, thereby letting a wheel turn, even if its partner is spinning in the air. When one wheel finds itself in the air, a diff lock become a rather essential off-road item.

How long do ARB lockers last?

Unrivalled Support. For total peace of mind, all ARB Air Lockers® are backed by a comprehensive, five-year, unlimited miles warranty. Coupled with ARB’s extensive dealer network, you can be sure we’ll be there to support you in the unlikely event of an issue.

Can you engage air lockers while driving?

ENGAGEMENT. An ARB Air Locker can be engaged at any speed as long as both wheels are spinning at the same rate and your foot is off of the accelerator.

Do all 4×4 have diff lock?

Not all versions of all 4X4s have diff-locks. Look for a button like this on a Nissan Y62 Patrol. On the right hand side of the picture there’s an icon of four wheels with an X between the rear axle – that’s the button to engage and disengage the rear locker.

Do you need a tank for air lockers?

LandCruiserPhil said: Any air source can run your air locker as long as it has the output on a regulator. You can divorce the tank on the Puma but you will need a small tank to run the Air locker.

Do you need an air tank for air locker?

All air lockers will leak a tiny bit when activated, if you have a tank it will keep the pump from cycling as often. Also, you need a tank to run tools, even my .

Do lockers help in mud?

Lockers will definitely help in mud. However, front being locked will make it hard to steer left and right and sometimes you have to saw the wheel to get unstuck. So, use as necessary. In my years of experience, the #1 piece of equipment you need to plow through mud is a big fat set of mud tires.

How long do air lockers last?

The O-ring seals ARB builds into Air Locker differentials actually have a lower wear coefficient than the metal surfaces they run against, and we have seen Air Locker O-rings last in excess of 500,000km and still perform flawlessly.

How fast can you drive with diff lock on?

Do not drive over 8 km/h (5 mph) when the differential is locked. Do not keep driving with the differential lock switch on.
